UNI-T UT61B+ 1000V True RMS Digital Multimeter

৳ 7,500.00

In stock

  • RMS Digital Multimeter
  • AC/DC voltage (V):1000V
  • Model: UT61B
  • Brand: UNI-T
  • Pack: 1 Piece per Pack
  • UT61 series are reliable true RMS digital multimeters with display counts of 6000 (UT61B /D ) and 22,000 (UT61E ). It can measure up to 1000V AC/DC.
  • Equipped with audible and visible alarms, this series can provide warnings, especially when measuring high voltage/current and temperature.
  • UT161 series are CE certified, suitable for the European market.

Features

  • True RMS
  • Data hold/backlight
  • Max/Min/Relative mode
  • USB communication
  • Input protection
  • Diode/continuity test
  • NCV (audible/visual alarm)
Specifications Range UT61B
Safety ratings CAT III 1000V/CAT IV 600V
AC voltage (V) 1000V ±(1%+3)
DC voltage (V) 1000V ±(0.5%+3)
AC (A) 10A ±(1.2%+5)
DC (A) 10A ±(1%+2)
Resistance (Ω) 60MΩ ±(1%+2)
Capacitance (F) 60mF ±(3%+5)
Frequency (Hz) 10MHz ±(0.1%+4)
Duty cycle (%) 0.1%~99.9% ±(2%+5)
Display count 6000
Bandwidth (Hz) 40Hz~500Hz
Analog bar 31
General Characteristics
Power 1.5V battery (R03) x 4
Product net weight 350g
Product size 190mm x 90mm x 50mm
Standard accessories Battery, gold plated test leads, USB cable, English manual
Standard individual packing Gift box, cloth bag
Standard quantity per carton 20pcs
Standard carton measurement 480mm x 370mm x 365mm
Standard carton gross weight 15.2kg
Optional accessories Bluetooth/APP
